Product Details
Place of Origin: China
Brand Name: Splendid
Certification: NSF 61/WRAS/KTW/ IATF16949
Model Number: Rubber Seal Gasket
Payment & Shipping Terms
Minimum Order Quantity: 100
Price: USD0.005 - USD0.9/PC
Packaging Details: Standard pack: bulk pack in plastic bag and carton box, special pack: paper tube, pallet
Supply Ability: 500000 pieces per month
Product Name: |
Rubber Seal Gasket |
Material: |
FKM FPM HNBR Silicone FVMQ Buna |
Service: |
OEM, ODM And Custom Service |
Drawing Format: |
JPEG, STEP, PDF |
Application: |
Automotive & Industry Equipment |
Certification: |
IATF16949/ NSF 61 / UL 157 |
Package: |
PP Bag + Carton Box |
Delivery: |
4-5 WEEKS |
Port: |
Shenzhen |
Product Name: |
Rubber Seal Gasket |
Material: |
FKM FPM HNBR Silicone FVMQ Buna |
Service: |
OEM, ODM And Custom Service |
Drawing Format: |
JPEG, STEP, PDF |
Application: |
Automotive & Industry Equipment |
Certification: |
IATF16949/ NSF 61 / UL 157 |
Package: |
PP Bag + Carton Box |
Delivery: |
4-5 WEEKS |
Port: |
Shenzhen |
Oil Resistance FKM Buna FPM Rubber Seal Gasket
Custom Compression Molded Rubber Gasket
Rubber Seal Gasket Description
A rubber gasket is a smart component that seals against both liquids and gases. They are the perfect solution to fill in irregularities and connect two surfaces together. The characteristics of a gasket are to be manipulable and able to warp into the tight space it is designed for.
Gaskets’ diverse properties make them suitable for a broad range of applications and can be used across many industries, such as:
Rubber gaskets can be used for:
You’ll most commonly find these types of gaskets between two pieces of pipe. Gaskets can also be used as a barrier between two objects, such as two metals or chemicals and are often used as protection from outside elements as well, such as in a camera lens, to combat moisture and dust.
Specification of Rubber Seal Gasket
| Brand Name | Splendid |
| Model Number | Rubber Seal Gasket |
| Processing Service | Compression molded & Injection Molded |
| Application | Customer's Request |
| Certification | NSF61, KTW, WRAS, IATF16949 |
| Color | Black and any color per pantone# |
| Curing system | sulfur cured, peroxide cured,bisphenol cured, platinum cured |
| Document | ISIR, PPAP, Control Plan... |
| Hardness | 20-90 Shore-A or IRHD |
| Service | OEM, ODM |
| Material Type | EPDM, F.VMQ, FKM, FFKM, HNBR, NEOPRENE, NBR, SILICONE, VAMAC... |
| Performance | Excellent chemical and physical property |
| Temperature | -70C - +315C |
Rubber Seal Gasket Materials
Gaskets can be created to standard specifications or bespoke to suit the needs of the application. They come in all shapes and sizes and can be created from a range of materials. These include a variety of common polymers; gasket sheet materials, such as synthetic, silicone and high performing engineering rubbers, as well as plastics, such as Acetal and PTFE. The range of materials available to create gaskets ensures that whatever the application there is an appropriate gasket material to fit the situation.
| NR | Natural Rubber | High tensile strength, good ductility |
| SBR | Styrene Butadiene Rubber | Uniform quality , less foreign matter but weak mechanical strength , can be mixed with NR , widely used in tire industry , shoe soles , tape , conveyor belt , etc |
| BR | Polybutadiene | |
| IIR | Butyl Rubber | Gas is less permeable and resistant to heat, sunlight and ozone |
| EPDM | Ethylene propylene Rubber | |
| CR | Polychloroprene Neoprene | Excellent heat aging, weather resistance, ozone resistance |
| XNBR | Carboxylated NBR / Carboxyl Butadience Acylonitrile | This gelatinization is rapid sulfur addition, short scorching time, short safe storage period, compared with the general NBR, excellent wear resistance, other characteristics are similar. |
| NBR | Nitrile Rubber ( Buna ) | Resistant to alcohol, it is the most common rubber raw material for oil seal and O-ring at present |
| HNBR | Hydrogenated Nitrile / Highly Saturated Nitrile ( HSN ) | Better temperature and weather resistance than NBR, similar oil resistance to NBR, used as seals for new R-134A refrigerant system. |
| PU | Polyurethane Rubber | High hardness, high elasticity, abrasion resistance are difficult compared to other rubbers, aging resistance, ozone resistance, oil resistance is also quite good, the general PU air tightness is good |
| CSM | Hypalon , Polyethylene | Good heat resistance, weather resistance, ozone resistance, acid resistance, often used for oxidation resistant drugs (except nitric acid, sulfuric acid) |
| ACM ( PA ) | Polyacrylate Rubber | It has good resistance to petrochemical oil, high temperature and weather. It is worse than general oil adhesive. It is widely used in automotive transmission system and power system seals. |
| ECO | Epichlorohydrin / Hydrin | Good oil resistance, heat resistance and ozone resistance |
| VAMAC | Vamac ( Ethylene / Acryllic ) AEM | Petrochemical oil resistance, heat resistance, weather resistance, ozone resistance are good, compared with PA has better temperature, widely used in automotive transmission system and power system seals. |
| SIL | Silicone Rubber | Tensile strength is worse than general rubber and does not have oil resistance, heat resistance, weather resistance, ozone resistance, low temperature are excellent, suitable for high and low temperature environment, and alcohol resistance. |
| FSIL | Fluorinated Silicone Rubber | Good resistance to oil, solvent and fuel oil, good resistance to high and low temperature, used in space parts, but mostly limited to static seals, its strength and wear resistance are not good. |
| FPM / FKM | Fluoro Carbon Rubber | High TEMPERATURE RESISTANCE IS BETTER THAN SIL, CHEMICAL resistance, MOST oil AND several solvents (EXCEPT KETones, LIPids), weather resistance, ozone resistance are good, cold resistance is poor, widely used in automobile, chemical plant parts |
Factory Profile and Advantage
1. Large production capacity and Short Delivery time: 2 factories of total 100 sets molding machines, we can bear large production capacity and our normal delivery is about 4-5 weeks.Special shorter delivery is available.
2. More than 9000 sizes o-ring tools are available. it will help you to get more buisness
3. Production line: standard line and dust free ( 300,000 ) line to produce special required parts.
4. Full range of material available: NBR, EPDM, SIL, FKM ( ETP, GF, GFLT, GLT ), HNBR, PU, PA, CR, NR, SBR, AFLAS, F.Silicone, Vamac, Butyl etc
5. Approvals: NSF, KTW, WRAS, UL, FDA etc. Special requirement is available.
6. Production line: o rings, quad rings, squre rings, gaskets, grommets, custom molded parts and rubber part bonded to metal.
Customer photos:
Certifications: IATF16949, NSF61, KTW, WRAS, UL 157
Package & Delivery:
FAQ
Q: Are you a manufacturer or a trading company ?
A: We're professional manufacturer of compression molded rubber sealing products, providing one-stop OEM & ODM service to all partners all over the world.
Q: What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the freight cost.
Q: What is your terms of payment?
A: 100% paid before shipping.
